Specialized Services
Balancing, grinding, and tube bending.
Specialized Services
We also have the following in house services to support your needs.
Balancing
(1) CEMB Horizontal Balancer, ZC4500, weigh capacity: 13,200 lbs
Grinding
- (1) Mattison Horizontal Surface Grinder, Travel: X=72” x Y=24” x Z= 26”
- (1) Chevalier FSG-1632 ADIV Horizontal Surface Grinder, Travel: X=32” x Y=16” x Z= 24”
Tube Bending
- (1) No. 3 Pines Hydraulic Bender
- (1) Horn Machine Tool CNC 100TSR Hydraulic Bender
- Square Tubing 1.0” x 1.0” x 0.65” wall to 3.0” x 3.0” x 0.25” wall w/ inside bend radius’ of 4.0”, 5.75”, 6.0” or 8.0”
- Rectangular Tubing 3.0” x 2.0” up to 0.25” wall forming on the minor axis w/ inside bend radius’ of 4.0”, 5.75”, 6.0” or 8.0”
- Rectangular Tubing 4.0” x 2.0” x up to 0.25” wall forming on the minor axis w/ inside bend radius of 4.0”
- Round Tubing 3.0 OD x 0.25” wall w/ inside bend radius 7.75”
